BMPRO GENIUS-11-HA Power Supply

SKU: GENIUS11HA

GENIUS-11-HA Power Supply

The Genius is an RV power supply providing the following features/functions:

AC input (240V nominal)
DC input (13.6V nominal)
Smart Battery Charger (Lead Acid)
Load LVD switch
Remote Load Isolating Switch Input
DC distribution for 10 loads with fuse protection (Terminal Block)
Temperature controlled fan

Designed and manufactured in Australia, the slim and sturdy Genius 30-35 chargers multiple deep cycle batteries faster.

To ensure that batteries are optimally charged and ready to use, the Genius has enhanced management capabilities such as boost charge, float charge, store charge and trickle charge modes. To ensure problem free charging, this device can also accept charge through an optional DC input.

The Genius has a range of battery protection features. They include reverse battery protection, battery current limit, over voltage protection, voltage current limit and fuse protection. The low voltage disconnect facility protects the battery against excessive draw. This device also hosts a thermally controlled fan to make sure that noise levels are kept to a minimum.

FEATURES

Suitable for high amperage applications
Various charge modes
Safe, flexible and reliable
Battery protection features including ? reverse, current limit, over voltage, voltage current limit and fuse protection
Compatible with all lead acid type batteries
Distribution board
Auxiliary input
Fault indicator

SPECIFICATIONS

Output current 35 Amps
Battery current limit 30A (+/-1A)
Input voltage 240VAC, 50Hz
Efficiency >90% (full load and 240Vac input)
Operating temperature 0°C to 50°C
Dimensions 316mm x 179mm x 87mm
Weight 4kg
